| Finition |
Race 29 |
| Année |
2015 |
| Photo |
|
| Couleur |
noir |
| Tailles / poids | L, M, S, XL |
| Matériau | Aluminium |
| Cadre | NEW 2015 META HT Trail 29??, Alloy 6061 triple butted, Top tube hidden cable path, tapered headtube |
| Fourche | ROCKSHOX Reba RL 29?? Solo Air, Low speed compression to Lock adjustment, Travel 100mm (80mm on XS), 15mm axle, Tapered steerer |
| Jeu de direction | RIDE ALPHA Semi integrated, tapered ZS44/56, 1.5 crown race, sealed bearing |
| Potence | RIDE ALPHA, Alloy 2014 Forged, 60mm, O° rise, Ø31,8mm |
| Cintre | RIDE ALPHA, Alloy 7075 double butted, 20mm rise, 730mm, Ø31,8mm |
| Grips | COMMENCAL lock on, Ø30mm, soft compound, Neon Orange logo |
| Freins | Formula New CR1 160mm/160mm with matchmaker |
| Dérailleur AR | SRAM X9 10 spd Type II medium cage |
| Boitier de pédalier | GXP BB 68mm, sealed bearings |
| Pédalier / guide chaine | RIDE Alpha Forged 2 pieces, 1x10, 32t Narrow-Wide black chainring, 170mm on XS/S, 175mm on M/L/XL |
| Chaine | KMC X10 |
| Cassette | SRAM PG1020 11-36t + E13 42t extra cog |
| Jantes | RIDE ALPHA 29?? Tubeless Ready, 32H double wall, 24,5mm, pin joint |
| Moyeux | RIDE ALPHA 32H, loose ball, light Quick Release skewer, 15mm front, 10x135mm rear |
| Rayons | Spoke Steel 1,8mm black - nipple brass 12mm black |
| Pneus | MAXXIS Ikon 29x2.2, 60 tpi |
| Tige de selle | RIDE ALPHA Alloy no offset Ø31,6mm, 350mm |
| Selle | Commencal Meta Trail, Crmo rails |
