Finition |
730 | 920 EVO | 930 | 930 | 930 | 940 | 940 | 940 | 940 |
Année |
2019 | 2023 | 2020 | 2021 | 2022 | 2020 | 2020 | 2021 | 2022 |
Photo |
|
|
|
|
|
|
|
|
|
Couleur |
|
|
|
noir , bleu |
noir , rouge |
|
|
|
|
Matériau | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
Cadre | Cadre en aluminium Strike eRide | Alloy Frame & Link Virtual 4 link kinematic VLK 29x2.6 / Boost 148x12mm UDH 150mm travel / Bosch Gen4 / Integr. removable Battery 1.8" Headtube, Central Kickstand Mount Integr. Cable | Alloy Frame | Alloy Frame / Virtual 4 link kinematic VLK, 27.5 | Alloy Frame / Virtual 4 link kinematic VLK, 27.5" and 29" compatible / geo adj. / Boost 148x12mm, 140mm travel / Bosch Gen4 / Integr. removable Battery, Tapered Headtube E2, Central Kickstand Mount, Range Booster Ready | Alloy Frame | Alloy Frame | Alloy Frame / Virtual 4 link kinematic VLK, 27.5 | Cadre aluminium / Virtual 4 link kinematic VLK 27.5" and 29" compatible / geo adj. / Boost 148x12mm 140mm travel / Bosch Gen4 / Integr. removable Battery Tapered Headtube E2, Central Kickstand Mount Range Booster Ready, d?battement avant: 140mm / arri?re: |
Amortisseur | Amortisseur customisé pour SCOTT avec réglage du débattement et de la géo., 3 modes, Débattement 140 - 90 - Système de blocage | X-Fusion NUDE eRIDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 150-100-Lockout / 205x55mm | X-Fusion NUDE Trunnion | X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 140-90-Lockout / 185x50mm | X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 140-90-Lockout / 185x50mm | X-Fusion NUDE Trunnion | X-Fusion NUDE Trunnion | X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 140-90-Lockout / 185x50mm | X-Fusion NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 140-90-Lockout / 185x50mm |
Fourche | Fourche RockShox 140 mm | RockShox 35 TK Air 15x110mm QR axle / 1.8" Tapered Steerer Reb. Adj. / 2 Modes / Lockout / 150mm travel / E-Bike | Marzocchi Z2 Air#Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer#44mm offset / Reb. Adj. / Lockout / 140mm travel / E-Bike | Marzocchi Z2 Air / eMTB+, Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel | Marzocchi Z2 Air / eMTB+, Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel | RockShox Recon RL Solo Air#15x110mm QR axle / Tapered Steerer#Reb. Adj. / 2 Modes / Lockout / 140mm travel / E-Bike | RockShox Recon RL Solo Air#15x110mm QR axle / Tapered Steerer#Reb. Adj. / 2 Modes / Lockout / 140mm travel / E-Bike | Marzocchi Z2 Air / eMTB+, Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel | Marzocchi Z2 Air / eMTB+ Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer 44mm offset / Reb. Adj. / Lockout / 140mm travel |
Freins | Freins à disque Shimano BR-MT520 | SRAM DB8 4 Piston Disc / Disk Centerline CL Rotors 200mm F&R | Shimano BR-MT420 4 Piston Disc#203mm CL rotor F&R#F: SM-RT30 / R: RT-EM300 | Shimano BR-MT420 4 Piston; disc Front: SM-RT30 CL 203mm / Rear: RT-EM300 CL 203mm | | Shimano BR-MT420 4 Piston Disc#203mm CL rotor F&R#F: SM-RT30 / R: RT-EM300 | Shimano BR-MT420 4 Piston Disc#203mm CL rotor F&R#F: SM-RT30 / R: RT-EM300 | Shimano BR-MT420 4 Piston; disc Front: SM-RT30 CL 203mm / Rear: RT-EM300 CL 203mm | Shimano BR-MT420 4 Piston, disques avant: SM-RT64 CL 203mm / arri?re: RT-EM600 CL 203mm |
Dérailleur AR | SRAM NX Eagle / 12 Speed | SRAM NX Eagle / 12 Speed | SRAM SX Eagle / 12 Speed | SRAM SX Eagle / 12 Speed | SRAM SX Eagle / 12 Speed | SRAM SX Eagle / 12 Speed | SRAM SX Eagle / 12 Speed | SRAM SX Eagle / 12 Speed | SRAM NX Eagle / 12 Speed |
Pédalier / guide chaine | | | FSA CK-320 / 165mm / 34T | | | FSA CK-320 / 165mm / 34T | FSA CK-320 / 165mm / 34T | | |
Cassette | SRAM PG1230 / 11-50 T | SRAM PG1210 / 11-50 T | SRAM PG1210 / 11-50 T | SRAM PG1210 / 11-50 T | | SRAM PG1210 / 11-50 T | SRAM PG1210 / 11-50 T | | |
Jantes | Shimano HB-MT400-B CL / 15x110mm; Shimano FH-MT400-B CL / Boost 12x148mm; Stainless Black; Syncros X-30S / 32H / 30mm / Sleeve Joint Tubeless ready | Moyeux avant Formula CL-811 / 15x110mm ; arri?re Formula CL-148S / Boost 148x12mm ; jantes Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready ; rayons Stainless Black | Syncros MD30 / 32H / 30mm / Pin Joint#Tubeless ready / Shimano HB-MT400-B CL / 15x110mm /Shimano FH-MT400-B CL / Boost 12x148mm | moyeux AV Formula CL-811 / 15x110mm; AR Formula CL-148S / Boost 148x12mm ; jantes Stainless Black | moyeux AV Formula CL-811 / 15x110mm; AR Formula CL-148S / Boost 148x12mm ; jantes Stainless Black | Syncros MD30 / 32H / 30mm / Pin Joint#Tubeless ready / Shimano HB-MT400-B CL / 15x110mm /Shimano FH-MT400-B CL / Boost 12x148mm | Syncros MD30 / 32H / 30mm / Pin Joint#Tubeless ready / Shimano HB-MT400-B CL / 15x110mm /Shimano FH-MT400-B CL / Boost 12x148mm | moyeux AV Formula CL-811 / 15x110mm; AR Formula CL-148S / Boost 148x12mm ; jantes Stainless Black | Moyeu av. Formula CL-811 / 15x110mm ; moyeu ar. Formula CL-148S / Boost 148x12mm ; jantes Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready |
Pneus | Front&Rear: Maxxis Rekon / 60TPI Kevlar Bead EXO / TR Tubeless ready Dual / 700 Series: 27.5x2.8" / 900 Series: 29x2.6" | | Front&Rear: Maxxis Rekon / 29x2.6" / 60TPI Wire Bead#EXO#Dual | | | Front&Rear: Maxxis Rekon / 29x2.6" / 60TPI Wire Bead#EXO#Dual | Front&Rear: Maxxis Rekon / 29x2.6 | Maxxis Rekon / 29x2.6 | |
Tige de selle | Syncros Dropper 2.5 / Remote 31.6mm / S size 100mm / M, L & XL 125mm | | Syncros Duncan Dropper 2.5 Remote#31.6mm / S size 100mm / M 125mm / L & XL 150mm | | | Syncros Duncan Dropper 2.5 Remote#31.6mm / S size 100mm / M 125mm / L & XL 150mm | | | |
