Finition |
720 | 920 | 920 | 920 |
Année |
2019 | 2020 | 2021 | 2022 |
Photo |
|
|
|
|
Matériau | Aluminium | Aluminium | Aluminium | Aluminium |
Cadre | Cadre en aluminium Strike eRide | Alloy frame | Alloy Frame / Virtual 4 link kinematic VLK, 27.5" and 29" compatible / geo adj. / Boost 148x12mm, 140mm travel / Bosch Gen4 / Integr. removable Battery, Tapered Headtube E2, Central Kickstand Mount, Range Booster Ready | Cadre aluminium / Virtual 4 link kinematic VLK 27.5" and 29" compatible / geo adj. / Boost 148x12mm 140mm travel / Bosch Gen4 / Integr. removable Battery Tapered Headtube E2, Central Kickstand Mount Range Booster Ready, d?battement avant: 140mm / arri?re: |
Amortisseur | Amortisseur customisé pour SCOTT avec réglage du débattement et de la géométrie, 3 modes, Débattement 140 - 90 - Système de blocage | X-Fusion NUDE Trunnion | X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 140-90-Lockout / 185x50mm | X-Fusion NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 140-90-Lockout / 185x50mm |
Fourche | Fourche RockShox 140 mm | RockShox Recon RL Solo Air#15x110mm QR axle / Tapered Steerer#Reb. Adj. / 2 Modes / Lockout / 140mm travel / E-Bike | Marzocchi Z2 Air / eMTB+, Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel | Marzocchi Z2 Air / eMTB+ Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer 44mm offset / Reb. Adj. / Lockout / 140mm travel |
Cintre | Syncros Hixon 2.0 Rise / Alloy 6061D.B. 20mm rise / 8° / 740mm Syncros Women Comfort lock-on grips | | | |
Freins | Freins à disque Shimano BR-MT520 | Shimano BR-MT420 4 Piston Disc#203mm CL rotor F&R#F: SM-RT30 / R: RT-EM300 | Shimano BR-MT420 4 Piston; disc Front: SM-RT30 CL 203mm / Rear: RT-EM300 CL 203mm | Shimano BR-MT420 4 Piston, disques avant: SM-RT64 CL 203mm / arri?re: RT-EM600 CL 203mm |
Dérailleur AR | SRAM NX Eagle / 12 Speed | SRAM SX Eagle / 12 Speed | SRAM SX Eagle / 12 Speed | SRAM NX Eagle / 12 Speed |
Boitier de pédalier | | FSA CK-320 / 165mm / 34T | | |
Pédalier / guide chaine | | | FSA CK-320 / 165mm / 34T | |
Cassette | SRAM PG1230 / 11-50 T | SRAM PG1210 / 11-50 T | SRAM PG1210 / 11-50 T | SRAM PG1210 / 11-50 T |
Jantes | Shimano HB-MT400-B CL / 15x110mm; Shimano FH-MT400-B CL / Boost 12x148mm; Stainless Black; Syncros X-30S / 32H / 30mm / Sleeve Joint Tubeless ready | Syncros MD30 / 32H / 30mm / Pin Joint#Tubeless ready/ Shimano HB-MT400-B CL / 15x110mm/Shimano FH-MT400-B CL / Boost 12x148mm | moyeux AV Formula CL-811 / 15x110mm; AR Formula CL-148S / Boost 148x12mm ; jantes Stainless Black | Moyeu av. Formula CL-811 / 15x110mm ; moyeu ar. Formula CL-148S / Boost 148x12mm ; jantes Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready |
Pneus | Front & Rear: Maxxis Rekon / 27.5x2.8" / 60TPI Kevlar Bead EXO / TR Tubeless ready / Dual | Front&Rear: Maxxis Rekon / 29x2.6" / 60TPI Wire Bead#EXO#Dual | Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual ? l'avant; Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual ? l'arri?re. | Avant : Maxxis Rekon / 29x2.6" / 60TPI Wire Bead EXO Dual / arri?re : Maxxis Rekon / 29x2.6" / 60TPI Wire Bead EXO Dual |
Tige de selle | Syncros Dropper 2.5 / Remote 31.6mm / S size 100mm / M, L 125mm | Syncros Duncan Dropper 2.5 Remote#31.6mm / S size 100mm / M 125mm / L 150mm | | |
